Model：培清JS-1070,JS-1070P
The use of the chemiluminescence imaging system has gradually replaced the traditional darkroom tabletting exposure test.
ABSTRACT
Peiqing JS-1070P Fluorescent&Chemiluminescence Gel Imaging System is all-in-one machine and it supports plug and play function. It applies to chemiluminescence, multi-color fluorescence detection and gel detection. Peiqing JS-1070P can capture razor-thin fluorescent light and fluorescent light by means of high resolution and low light-level CCD which combines large aperture and motorized zoom lenses. Deep cooling CCD can remove background noise to the most degree. Large aperture and motorized zoom can capture weak light furthest. Optional various fluorescent light sources and electric filter wheel satisfy experimental demand for nucleic acid imaging and ECL imaging.
PERFORMANCE FEATURES
?It can capture and analyze image by means of built-in 17 inches LED infrared multi-touch. No more needed of external PC.
?It can acquire the chemiluminescence experimental result rapidly by means of motorized zoom lens (F/0.85) and high sensitivity cooling CCD. It helps experimenter to avoid traditional way of darkroom exposure.
?Full-automatic computer control for AF, transillumination and reflected light.
?Observe gel and chemiluminescence image in real time.
?Support auto-exposure, one-touch capture image of western blot.
?Support one-touch auto-overlap marker image and chemiluminescence image, and generate three kinds of chemiluminescence images.
?Support to set the number of sample, start and end of exposure time, also support to multi-capture in order to access to the best performance.
APPLICATION
Chemiluminescence detection Western Lightning, ECL, ECL plus, CDP Star, SuperSignal, CSPD, LumiGlo, etc.
SPECIFICATIONS
?CPU:intel3205U, quad-core
?Memory: 2GB (The maximum capacity to support 4 GB)
?HardDisk: SSD 128 GB
?Wifi: YES
?Network adapter: 100Mbps Ethernet card
?Screen: 17 inches LED infrared multi-touch screen, response time is 8 MS, Induction strength is 15G, number of clicks > 600 million
?Cooling CCD: high resolution, low illumination level, made in USA (chip: Sony ICX694)
?Cooling function: semiconductor refrigeration
?Quantum efficiency : High QE: 80%
?Cooling temperature: below 65℃ (absolute temperature -45℃, and CCD temperature shows in panel in real time)
?Pixel: 2750 x 2200(605M)
?Bin: 1x1, 2x2, 3x3, 4x4, 6x6, 8x8
?Lens: F/0.85, 4/3 inches motorized zoom lens, support AF.
?A/D Conver: 16 bit(0-65535)
?Pixel size: 6.45x 6.45 um
?Dynamic range: > 4.6
?Zoom: drawer-style AF platform with two layers, compatible with various thicknesses samples
?Capture: Support one-touch auto-overlap marker image and chemiluminescence image, and generate three kinds of chemiluminescence images.
?One click shooting: Support auto-exposure, one-touch capture image of western blot.
?lifting platform(Optional): computer stepless control lifting platform, automatically locate sample
?Secondary light source: transmission: LED white light panel; reflection on both sides: white light source(luminescence), and computer can adjust the brightness
?Filter station : No
?Filter : No
?Timing shutdown: 0-60 minutes
?Shooting area: white light: 18x18cm
?Enterprise certification: “Shanghai high and new tech enterprises”, third prize in “Shanghai science and technology awards”
?Dimension: 39 x 35 x 59 CM
?Software: ECL SensiAnsys, ECL SensiCapture ,professional image collection and analysis system
